Power Pruner® Pole Saws
Specifications
Model: PPF-225
| Specification | Details |
|---|---|
| Length | 2,455 mm (96.7 in.) |
| Width | 246 mm (9.69 in.) |
| Height | 235 mm (9.25 in.) |
| Weight (dry) | 6.3 kg (13.9 lb.) |
Engine
| Specification | Details |
|---|---|
| Type | Air-cooled, two-stroke, single-cylinder gasoline engine |
| Bore | 32.2 mm (1.27 in.) |
| Stroke | 26.0 mm (1.02 in.) |
| Displacement | 21.2 cc (1.29 cu. in.) |
| Exhaust | Spark arrestor muffler or spark arrestor muffler with catalyst |
| Carburetor | Diaphragm with purge pump |
| Ignition System | Flywheel magneto, capacitor discharge ignition type |
| Spark Plug | NGK BPM-8Y - Gap 0.65 mm (0.026 in.) |
Fuel & Oil
| Specification | Details |
|---|---|
| Fuel Type | Mixed (gasoline and two-stroke oil) |
| Fuel/Oil Ratio | 50:1 - Power Blend XT™ ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345-FD, two-stroke, air-cooled engine oil. |
| Gasoline | Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl alcohol, or 15% MTBE. Do not use alternative fuels such as E-15 or E-85. |
| Oil | Power Blend XT™ Premium Universal 2-Stroke Oil |
Additional Specifications
| Specification | Details |
|---|---|
| Fuel Tank Capacity | 0.44 L (14.9 US fl. oz.) |
| Starter System | Automatic Rewind Starter |
| Clutch | Centrifugal Type |
| Drive Shaft | 6.35 mm (1/4 in.) flexible shaft |
| Sprocket Type | 6 tooth spur, 9.53 mm (3/8 inch) pitch |
| Shaft Tube Assembly | 25 mm (1 in.) Galvanized Steel |
| Gear Case Ratio | 1.53 |
Additional Features
| Specification | Details |
|---|---|
| Oiling System | Automatic |
| Chain Oil Capacity | 0.2 L (6.76 oz.) |
| Handles | Right-hand grip with throttle trigger and throttle trigger lockout / Left foam hand grip |
| Shoulder Harness | Standard |
Engine Speeds
| Specification | Details |
|---|---|
| Idle Speed | 2,750 RPM |
| Clutch Engagement Speed | 4,300 RPM |
| Wide Open Throttle Speed | 10,900 RPM |
Guide Bar & Saw Chain
| Specification | Details |
|---|---|
| Guide Bar & Saw Chain (91) | 254 mm (10 in.); 9.53 mm (3/8 inch) pitch chain, 0.050 gauge |
