Generators & Inverters
Specifications
MODEL NUMBER: EGi-3600LN
Generator Specifications
| Specification | Details |
|---|---|
| Type | Silent inverter |
| Rated Frequency (Hz) | 50 |
| Rated Voltage (V) | 240 |
| Rated Output Power (kW) | 1 |
| Power Factor | 3.0 |
| AC Output Quality | ISO8528 G2 |
| Charging Voltage (DC) (V) | 12 |
| Charging Current (DC) (A) | 8.3 |
| Overload Protection (DC) | Non-fuse protector |
Engine Specifications
| Specification | Details |
|---|---|
| Engine | R210-i |
| Engine Type | Single cylinder, 4-stroke, forced air cooling, OHV |
| Displacement (cc) | 212 |
| Fuel Type | Unleaded gasoline |
| Fuel Tank Capacity (L) | 9.0 |
| Oil Capacity (L) | 0.6 |
| Spark Plug Model No. | F6RTC |
| Valve Clearance (Intake/Exhaust) | 0.05 - 0.10 mm |
| Starting Mode | Recoil / Electric |
Generator Set Specifications
| Specification | Details |
|---|---|
| Dimensions (L×W×H) (mm) | 643×480×498 |
| Net Weight (kg) | 46 |
| Spark Arrester Equipped | Yes |
